PS Audio DirectStream Power Plant 20

Reference standard AC power delivery and protection

Demanding systems require remarkable power. The DirectStream P20 Power Plant is our finest expression of the art of delivering protected, pure, regulated, distortion-free AC power.

With peak power levels of 3600 watts, no equipment can tax the mighty P20. Finally, your most coveted components have the opportunity to unleash their full potential, no longer hindered by dynamic drops in AC caused by the unavoidable resistance of the miles of wiring between you and the power station. DirectStream P20 regulates both long-term fluctuations and peak dynamic without deviation, ensuring a solid foundation from which to build a state-of-the-art system. Its low output impedance and unhindered AC delivery are equivalent to less than 50 feet of 12 gauge wire connected directly to your city power source without the connecting miles of wire, the many transformers, and the multiple neighbors weakening and contaminating your power. The most demanding music systems require nothing less than the P20.

The DirectStream Power Plant 20 is our most powerful AC regenerator ever with 2000 watts of pure regenerated power, and the first to accept both 20 amp and 15 amp power cables. The massive P20 is our finest expression of the art of pure power delivery, providing more than enough power for an entire system. Regardless of incoming power quality the P20 outputs clean, protected, low impedance, regulated power you can count on for the most demanding systems in the world.

Don’t starve your music. A P20 gives you improved dynamics, far better bass and a much bigger, open soundstage. Take one home and try it today.

Shipping typically 1-3 days
  • Built in Boulder
  • 2000 VA output
  • Passively cooled
  • 40% more power
  • 3X lower impedance than any Power Plant yet
  • 13 EU/AU/GR/UK outlets
  • 10 amp AC input EU/AU/GR/UK
  • 230 volt Regulated EU/AU/GR/UK
  • Range 200 –285VAC EU/AU/GR/UK
  • 100% regenerated AC
  • MultiWave
  • Pure Sine Wave generated through DSD (PDM) engine
  • Integrated oscilloscope
  • THD meter
  • Improvement meter
  • Power meter
  • Control over the web
  • Adjustable output voltage
  • Color touchscreen
  • Field upgradable
  • 105 pounds boxed
  • 17W x 11H x 14D

Environment Specification

US/JP

Europe/Asia

Location

Indoor use only

Indoor use only

Duty Cycle

Suitable for continuous operation

Suitable for continuous operation

Moisture Sensitivity

Not sealed against moisture

Not sealed against moisture

Operating Humidity

<80%rh

<80%rh

Storage Temperature

-40C to +40C

-40C to +40C

Operating Temperature

0C to 40C

0C to 40C

Max Operating Altitude

12,000’ (3500m)

12,000’ (3500m)

Electrical Supply Nominal Rating

120V 15A 60Hz US
100V 15A 50/60 Hz JP

230V 10A 50/60Hz

Instrument Specification



Unit Dimensions

17” W x 14” D x 11” H (43cm W x 36cm D x 27.9 cm H)

17” W x 14” D x 11” H (43cm W x 36cm D x 27.9 cm H)

Unit Weight

96 lbs ( 43.5kg)

96 lbs ( 43.5kg)

Shipping Dimensions

23” x 22” x 17” ( 58cm x 55.8cm x 43 cm)

23” x 22” x 17” ( 58cm x 55.8cm x 43cm)

Shipping Weight

105 lbs (47kg)

105 lbs (47kg)

Nominal Input Voltage

95 – 145 VAC

200 –285VAC

Maximum Continuous Load

2000VA

2000VA

Maximum Peak Load

3600VA

3600VA

Voltage Regulation

>1V

>1V

Output Distortion (Resistive Load)

<0.5%

<0.5%

Output Distortion (Reactive Load)

<0.5%
0.1% typical

<0.5%
0.1% typical

Output Impedance

<0.005 ohm

<0.005 ohm

Noise Reduction

100kHz – 2MHz >80dB

100kHz – 2MHz >80dB

Efficiency @1500 VA

>85%

>85%

Standby Power Consumption



Input Frequency

45 – 65 Hz

45 – 65 Hz

Under Voltage Limit

Continuous -10% of setting 15 sec duration -15% of setting

Continuous -10% of setting 15 sec duration -15% of setting

Over Voltage Limit

Continuous 5% of setting 15 sec duration 10% of setting

Continuous 5% of setting 15 sec duration 10% of setting

Energy Dissipation

2040J

5040J

Peak Current Surge

180,000A

180,000A

Clamp Level

340V

775V

DC Trigger Configuration

Tip Positive

Tip Positive

DC Trigger Voltage

5 – 15Vdc

5 – 15Vdc
