ATC SIA2-100 Integrated Amplifier

Compact in size (2/3 width) yet offering high power output and exceptional resolution, this integrated amplifier with on-board DAC is ideally suited to driving ATC’s small & mid-size passive loudspeakers and a very wide range of loudspeakers from other manufacturers.  Understated styling makes it easy to integrate with partnering equipment whilst its small footprint occupies very little space in the home.

Shipping typically 5-7 days
  • 2 x line level analogue inputs.
  • 3 x digital inputs: USB, Coaxial, TOSLINK.
  • Premium AKM 32-bit DAC.
  • USB digital input supports up to 384kHz PCM data and native DSD256.*
  • ATC Discrete MOSFET Output Stage with 100W/Ch. Max. Cont. Power.
  • Headphone amp featuring discrete output stage.
  • Handmade in England.
  • 6 year warranty.
  • *DSD256 support via PC only (up to DSD128 via Mac).

Max. Power Output: 100W (Continuous Av. 8 Ohms, 1kHz, both channels driven)
Line Inputs: Two, stereo (one with additional front panel 3.5mm jack)
Line Input Sensitivity: 500mV
Input Impedance: 13k8 Ohms
Line Outputs: One, stereo
Overload Capacity: 13dB
Line Output Impedance: 10 Ohms
Frequency Response: < 2Hz – > 250kHz (@ -3dB)
Total Harmonic Distortion: 1kHz <0.0015% (-96dB), 10kHz <0.002% (-90dB)
Crosstalk: >80dB (10Hz – 20kHz)
S+N/N Ratio: > 96dB (Wide band), > 108dB (DIN), > 112dB (IEC “A”)

SIA2-100 Digital Inputs – Coaxial & Optical

Distortion: 1kHz <0.0015% (-96dB ), 10kHz <0.005% (-86dB)
Frequency Response: 20Hz – 20kHz (+/- 0.1dB)
S+N/N Ratio: >100dB (IEC “A”)
Word Lengths Supported: 16 – 24 Bit
Sample Rates Supported: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 192kHz *
* 192kHz supported via coaxial input only

SIA2-100 Digital Inputs – USB (PCM)

Distortion: 1kHz <0.0015% (-96dB ), 10kHz <0.005% (-86dB)
Frequency Response: 20Hz – 50kHz (+/- 0.1dB)
S+N/N Ratio: >100dB (IEC “A”)
Word Lengths Supported: 16 – 32 Bit
Sample Rates Supported: 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96.0kHz, 176.4kHz, 192.0kHz, 352.8kHz, 384.0kHz

SIA2-100 Digital Inputs – USB (DSD)

Frequency Response: 10Hz – 50kHz (+/- 0.1dB)
S+N/N Ratio: >100dB (IEC “A”)
DSD Rates Supported: Windows DSD64, DSD128, and DSD256, MAC OS DSD64 and DSD128

SIA2-100 Mains Power

Voltage: 115/230V AC 50/60Hz (internally selectable). 100v AC via dedicated transformer. Mains voltage selection is to be carried out by ATC only.
Maximum Power Consumption: 400W
SIA2-100 Physical
Dimensions: 113 x 315 x 315mm / 4.4 x 12.4 x 12.4" - Dimensions exclude rear panel connectors. Take care to leave space behind the unit for connectors and cables.
Weight: 9.70kg/24.39lbs
