PS Audio P5 Power Regenerator

PS Audio P5 Power Regenerator
  Zoom
 PS Audio P5 Power RegeneratorPS Audio P5 Power Regenerator
£3,499.00
(£2,915.83 Exc. VAT)



Call: 01892 532995

Free U.K. Delivery

Availability

Enquire now to purchase
01892 532 995

  • 1250 watts of pure regenerated power handling
  • Surge protection
  • Spike protection
  • Regulated output voltage
  • Whisper cooling fan
PS Audio
Secured by Thawte

Why buy from us?

PS Audio P5 Power Plant

Generate new AC power for best performance

Power Plants take your incoming AC power and regenerates new sine-wave-perfect, regulated high current AC power. In the process of regeneration any problems on your power line such as low voltage, distorted waveforms, sagging power and noise are eliminated. The results are both audibly and visually stunning when powering either audio or video products.

The P5 produces pure and perfect AC and is the power source of choice for almost any size system. Smaller than the P10, this workhorse of a product should be the foundation on which you build your system when a P10 isn’t in the cards.

The P5 Power Plant has 1250 watts of pure regenerated power handling any size system you want to power. From medium to large power amplifiers to the smallest pieces of source equipment, the P5 will work magic on your system’s performance. Dynamics and openness are breath-taking with the P5. This is clearly one of the most important pieces of audio equipment you can own.

Shipping typically 2-3 days
  • 1200 VA output
  • Built in Boulder
  • Surge protection
  • Spike protection
  • Regulated output voltage
  • Ten times lower distortion
  • Whisper cooling fan
  • 100% regenerated AC
  • Integrated oscilloscope
  • THD meter
  • Control over the web or network
  • Adjustable output voltage



Environment Specification
US/JP Europe/Asia
Location Indoor use only Indoor use only
Duty Cycle Suitable for continuous operation Suitable for continuous operation
Moisture Sensitivity Not sealed against moisture Not sealed against moisture
Operating Humidity <80%rh <80%rh
Storage Temperature -40C to +40C -40C to +40C
Operating Temperature 0C to 40C 0C to 40C
Max Operating Altitude 12,000’ (3500m) 12,000’ (3500m)
Electrical Supply Nominal Rating 120V 15A 60Hz US 230V 10A 50/60Hz
100V 15A 50/60 Hz JP
Instrument Specification
Unit Dimensions 17” W x 14” D x 4” H (43cm W x 36cm D x 10.16 cm H) 17” W x 14” D x 4” H (43cm W x 36cm D x 10.16 cm H)
Unit Weight 37 lbs ( 16.7kg) 37 lbs ( 16.7kg)
Shipping Dimensions 24” x 21” x 10” ( 61cm x 53cm x 25cm) 24” x 21” x 10” ( 61cm x 53cm x 25cm)
Shipping Weight 48 lbs (21.7kg) 48 lbs (21.7kg)
Nominal Input Voltage 95 – 145 VAC 200 –285VAC
Maximum Continuous Load 1000VA 1500VA
Maximum Peak Load 1200VA 1800VA
Voltage Regulation 0.5V 1V
Output Distortion (Resistive Load) <0.5% <0.9%
Output Distortion (Reactive Load) <0.5% <0.9%
Output Impedance <0.015 ohm <0.015 ohm
Noise Reduction 100kHz – 2MHz >80dB 100kHz – 2MHz >80dB
Efficiency @1200 VA >85% >85%
Input Frequency 45 – 65 Hz 45 – 65 Hz
Under Voltage Limit Continuous -10% of setting 15 sec duration -15% of setting Continuous -10% of setting 15 sec duration -15% of setting
Over Voltage Limit Continuous 5% of setting 15 sec duration 10% of setting Continuous 5% of setting 15 sec duration 10% of setting
Energy Dissipation 2440J 3670J
Peak Current Surge 144,000A 84,000A
Max Surge Voltage 6,000V 6,000V
Clamp Level 330V 800V
DC Trigger Configuration Tip Positive Tip Positive
DC Trigger Voltage 5 – 15Vdc 5 – 15Vdc
