PS Audio DirectStream Power Plant 12

Generate new AC power for best performance

The DirectStream Power Plant 12 is the successor to the venerable P5 Power Plant. The P12 is completely redesigned from the ground up with three times lower output impedance, lower distortion, a new FPGA based DSD sine wave generator, and an improved level of performance never before attained by any Power Plant of its size. Power Plants take your incoming AC power and regenerate new sine-wave-perfect, regulated high current AC power. In the process of regeneration any problems on your power line such as low voltage, distorted waveforms, sagging power and noise are eliminated. The results are both audibly and visually stunning when powering either audio or video products. Further, the level of protection afforded connected equipment is extraordinary. Feel 100% confident that a P12 will provide pure and safe power under any condition.

The DirectStream Power Plant 12 features an all new analog power amplifier and FPGA sine wave generator based on pure, clean, analog DSD (PDM). The P12 is our most powerful compact regenerator with 1250 watts of pure power. From medium to large power amplifiers to the smallest pieces of source equipment, the P12 will work magic on your system’s performance. Dynamics and openness are breathtaking with the P12.

This is clearly one of the most important pieces of audio equipment you can own. Expect far better micro and macro dynamics as well as a cleaner, lower noise background. Don’t starve your music or risk damaging your equipment. A P12 gives you greatly improved performance and safety from just plugging into the wall socket and far better dynamics, bass and a much bigger, open soundstage than any passive power conditioner on the market.

Why settle for anything but a Power Plant? Take one home and try it today.

Shipping typically 2-3 days
  • Built in Boulder
  • 1200 VA output
  • 3X lower impedance than P5
  • 8 outlets US
  • 15 amp AC input US
  • 120 volt regulated US
  • Range 95 – 145 VAC US
  • 4 EU/AU/GR/UK outlets
  • 10 amp AC input EU/AU/GR/UK
  • 230 volt Regulated EU/AU/GR/UK
  • Range 200 –285VAC EU/AU/GR/UK
  • 100% regenerated AC
  • 4 outlets
  • MultiWave
  • Pure Sine Wave
  • Integrated oscilloscope
  • THD meter
  • Improvement meter
  • Power meter
  • Control over the web
  • Adjustable output voltage
  • Colour touchscreen
  • Field upgradable
  • 48 pounds boxed
  • 17W x 4H x 14D

Environment Specification

US/JP

Europe/Asia

Location

Indoor use only

Indoor use only

Duty Cycle

Suitable for continuous operation

Suitable for continuous operation

Moisture Sensitivity

Not sealed against moisture

Not sealed against moisture

Operating Humidity

<80%rh

<80%rh

Storage Temperature

-40C to +40C

-40C to +40C

Operating Temperature

0C to 40C

0C to 40C

Max Operating Altitude

12,000’ (3500m)

12,000’ (3500m)

Electrical Supply Nominal Rating

120V 15A 60Hz US
100V 15A 50/60 Hz JP

230V 10A 50/60Hz

Instrument Specification



Unit Dimensions

17” W x 14” D x 4” H (43cm W x 36cm D x 10.16 cm H)

17” W x 14” D x 4” H (43cm W x 36cm D x 10.16 cm H)

Unit Weight

37 lbs ( 16.7kg)

37 lbs ( 16.7kg)

Shipping Dimensions

24” x 21” x 10” ( 61cm x 53cm x 25cm)

24” x 21” x 10” ( 61cm x 53cm x 25cm)

Shipping Weight

48 lbs (21.7kg)

48 lbs (21.7kg)

Nominal Input Voltage

95 – 145 VAC

200 –285VAC

Maximum Continuous Load

1000VA

1500VA

Maximum Peak Load

1200VA

1800VA

Voltage Regulation

0.5V

1V

Output Distortion (Resistive Load)

<0.5%

<0.9%

Output Distortion (Reactive Load)

<0.5%
0.1% typical

<0.9%
0.1% typical

Output Impedance

<0.008 ohm

<0.008 ohm

Noise Reduction

100kHz – 2MHz >80dB

100kHz – 2MHz >80dB

Efficiency @1200 VA

>85%

>85%

Input Frequency

45 – 65 Hz

45 – 65 Hz

Under Voltage Limit

Continuous -10% of setting 15 sec duration -15% of setting

Continuous -10% of setting 15 sec duration -15% of setting

Over Voltage Limit

Continuous 5% of setting 15 sec duration 10% of setting

Continuous 5% of setting 15 sec duration 10% of setting

Energy Dissipation

2440J

3670J

Peak Current Surge

144,000A

84,000A

Max Surge Voltage

6,000V

6,000V

Clamp Level

330V

800V

DC Trigger Configuration

Tip Positive

Tip Positive

DC Trigger Voltage

5 – 15Vdc

5 – 15Vdc
